TYB uthotho lwesigaba esithathu esisigxina umazibuthe synchronous motor Umfanekiso Featured

Uthotho lwe-TYB yesigaba sesithathu semagnethi esisigxina ye-synchronous motor

Inkcazelo emfutshane:

Ilahleko yenkqubo yokuvuselela iyancipha kwaye ukusebenza kakuhle kuphuculwe;izinga elibanzi lokonga amandla li-10-50%.

I-excitation winding and excitation power supply iyakhululeka, isakhiwo silula kwaye umsebenzi uthembekile.

I-motor yemagnethi esisigxina yomhlaba enqabileyo ihlangene kwisakhiwo, incinci ngobukhulu kunye nokukhanya kobunzima;isiseko sincitshiswe ngama-1-2 ubukhulu.

Ubungakanani kunye nokumila kwe-motor kuyaguquguquka kwaye kuyahluka;ulungelelwaniso olungelulo oluqhelekileyo lunokwenzeka.

Thumela i-imeyile kuthi

Iinkcukacha zeMveliso

Iithegi zeMveliso

IiNkcazo zeMveliso

Idatha ephambili yobuchwephesha yochungechunge lwe-TYB yenqanaba lesithathu isigxina semagnethi motor synchronous

Umzekelo	Uluhlu lwamandla (kW)	Uluhlu lwamandla ombane (V)	Ikalwe ngoku (A)	Uluhlu lwe-FM (Hz)	Uluhlu lwesantya (r/min)	I-torque elinganisiwe (Nm)	Umatshini no
I-TYBX30-42-82	0.03-0.3-0.5	23-230-380	1.8	5-50-82	150-1500-2460	1.91	801
I-TYB75-42-80	0.15-0.75-1.2	48-238-380	3.2	10-50-80	300-1500-2400	4.78	802
I-TYB110-4	0.22-1.1	76-380	2.8	10-50	300-1500	7	90S
I-TYB150-4	0.3-1.5	76-380	3.4	10-50	300-1500	9.55	90L
I-TYBZ150-4	0.19-0.94-1.5	48-238-380	3.4	10-50-80	300-1500-2400	5.97	90L
I-TYB138-42-80	0.17-1.38-2.2	29-238-380	4.5	6-50-80	180-1500-2400	8.75	100L2
I-TYB220-4	0.44-2.2	76-380	5	10-50	300-1500	14	100L1
I-TYBZ220-4	0.28-1.38-2.2	48-238-380	5.2	10-50-80	300-1500-2400	8.75	100L1
I-TYB300-4	0.6-3	76-380	6.2	10-50	300-1500	19.1	100L2
I-TYBZ300-4	0.38-1.88-3	48-238-380	6.2	10-50-80	300-1500-2400	11.94	100L2
I-TYB325-42-80	0.39-3.25-5.22	39-238-380	10	6-50-80	180-1500-2400	20.69	112M
I-TYB400-4	0.8-4	76-380	9	10-50	300-1500	25.47	112M
I-TYB550-4	1.1-5.5	76-380	11	10-50	300-1500	35	132S
I-TYB750-4	15-7.5	76-380	15	10-50	300-1500	48	132M
I-TYB1100-4	2.2-11	76-380	23	10-50	300-1500	70	160L
I-TYB1500-4	3-15	76-380	27	10-50	300-1500	95.5	160L
I-TYBX60-65-100	0.06-0.6-1.2	19-140-280	4.5	5-50-100	100-1000-2000	5.73	90S
I-TYBZ80-6	0.06-0.75-1.1	20-253-380	3.4	4-50-75	80-1000-1500	7	90S
I-TYBX52-67-126	0.26-0.52-1.31	75-150-378	4.5	25-50-126	500-1000-2520	4.97	90L
I-TYB75-6	0.38-0.75-2.25	63-125-375	5.6	20-50-150	500-1000-3000	7.13	112M
I-TYB220-6	0.73-1.83-2.2	126-317-380	4.9	20-50-60	400-1000-1200	17.5	112M
I-TYB300-6	0.6-3	76-380	6	10-50	200-1000	28.65	112M
I-TYB220-8	0.44-2.22	76-380	5	10-50	150-750	28.01	112M
I-TYBX400-8-50	0.27-4	26-380	10	3.33-50	50-750	50.93	180M
I-TYB630-8	3.15-6.3-12.6	95-190-380	28	25-50-100	375-750-1500	80	180L
I-TYB750-8	1.2-7.5-15	30-190-380	30	8-50-100	120-750-1500	96	180L
I-TYB900-8	1.13-9-18	24-190-380	35	6.25-50-100	94-750-1500	110	180L
I-TYB1100-8	1.37-11-22	24-190-380	45	6.25-50-100	94-750-1500	140.2	225M
I-TYB1500-8	1.88-15-30	24-190-380	55	6.25-50-100	94-750-1500	191	225M

Iinkcukacha eziphambili zobuchwephesha ze-FTY uthotho lwesigaba sesithathu semagnethi esisigxina ye-synchronous motor

Umzekelo	Uluhlu lwamandla (kW)	Uluhlu lwamandla ombane (V)	Ikalwe ngoku (A)	Uluhlu lwe-FM (Hz)	Uluhlu lwesantya (r/min)	I-torque elinganisiwe (Nm)	isihlalo cabin no
FTY550-4	363-550-1210	73-110-242	4.7	33-50-110	990-1500-3300	3.5	90L
I-FTY750-4G	225-750-1200	66-220-352	3.3	15-50-80	450-1500-2400	4.78	90L
FTY1000-4C	300-1000-1600	66-220-352	4.4	15-50-80	450-1500-2400	6.37	90L
I-FTY1620-4	710-1620-2300	112-254-360	5.5	22-50-71	660-1500-2130	10.31	100L1
FTY1800-4	790-1800-2556	112-254-360	7	20-50-71	600-1500-2130	11.46	132S
FTY650-41-170	650-2000	112-380	3.5	50-170	1500-5100	4.14	100L1
FTY4000-4-60	800-4000-4800	63-317-380	9.5	10-50-60	300-1500-1800	25.47	112M

Ngenxa yeemodeli ezininzi kunye neenkcukacha, nceda ufowunele +86 186 0638 2728 ngeenkcukacha ezithile.
2. Iimeko zokusetyenziswa
Ubushushu be-Ambient: -15℃～40℃
Ukuphakama: akukho ngaphezu kweemitha ezili-1000
Amandla alinganisiweyo: 0.25kw-2400kw, non-standard ingenziwa ngokwezifiso;
Umbane olinganisiweyo: 380V, 220V, amanye amandla ombane ozikhethelayo
Ireyithiwe rhoqo: 50Hz, 100Hz, 200Hz, ezinye iifrikhwensi ozikhethelayo
Inkqubo yokusebenza: inkqubo yokusebenza eqhubekayo (S1)
Iklasi yoKhuselo: IP54/IP55
Iklasi yokugquma: F
Indlela yokupholisa: IC411/IC416
Indlela yoqhagamshelwano: Y/△

Ukusetyenziswa kweMveliso

Ukuxhaswa kwemizi-mveliso: izixhobo zokuqhuba ishishini, ezinjengoomatshini belaphu, ukuxhaswa kwempompo yamanzi, inkxaso yefeni, izixhobo zemigodi, njl.
●Ezothutho: iitram, izixhobo ezincedisa inqwelomoya, iinqanawa, njl.
●Indawo ye-aerospace: iirokhethi, iinqwelomoya, iziphekepheke, iishuttles zasemkhathini, njl.
●Indawo yokhuselo: iitanki, imijukujelwa, iinkwili, iinqwelomoya, njl.
●Ukuveliswa kwamandla kwimizi-mveliso: ukuveliswa kwamandla omoya, ukuveliswa kwamandla obushushu benkunkuma, ukuveliswa kombane wamanzi, iijenereyitha zeeseti zejenereyitha ezivuthayo zangaphakathi kunye nee-exciters ezincedisayo kwiijenereyitha ezinkulu, njl.

FAQ

Kutheni le nto iimotor zemagnethi ezisisigxina zigcina amandla?
Impendulo: Ukusebenza okuphezulu: kunokufikelela kwinqanaba lesibini lesizwe lamandla okusebenza kakuhle, kwaye ezinye iinkcukacha zifikelela kwinqanaba lokuqala lokusebenzisa amandla.
Ulwakhiwo oluphezulu: iimagnethi ezisisigxina zisetyenziswa kwi-rotor, akukho lahleko yokuvuselela, akukho lahleko yokungqubana kunye nokulahleka kombane phakathi kweebhrashi kunye namakhonkco atyibilikayo.
Amandla aphezulu: Xa i-motor yemagnethi esisigxina ikwintsebenzo eqhelekileyo, isantya se-rotor siyafana nesantya se-stator magnetic field, akukho okwangoku kwi-rotor squirrel cage bars, kwaye i-current induced kwi-stator iyancipha, ngoko ke amandla into iphezulu.Inoluhlu olubanzi lokusebenza kwezoqoqosho: umthwalo wemagnethi esisigxina utshintsho lwe-synchronous motor, kwaye umbane unokuba ngaphezu kwe-0.9.

Yintoni umphumo wokonga amandla wemagnethi esisigxina ye-synchronous motor?
Impendulo: Ngokweemeko zokusebenza ezahlukeneyo zezixhobo, umphumo wokonga amandla uphakathi kwe-5% kunye ne-50%.
